O Spectroscopy Kit includes:
- Halogen Light Source with power supply (default the US plug).
- High performance O-Spectrometer with an extended wavelength range of 200-1000nm.
- Deuterium or Halogen Light Source
- A Cuvette holder with a cover and two preinstalled coated Plano-Convex Lens, Ø1/2″, f = 20.0 mm.
- A set of Quartz cuvettes – 2 items.
- 2 sets of Optical fiber core diameter of 100µm and 0.5m long.
All items are packed in a convenient modern zip case that can be stored and carried around safely.
Thunder View Software – The software allows users to control the spectrometer for data acquisition. This includes their ability to acquire emission spectra and determine optimal wavelengths for kinetic experiments.
Top Features
- High performance Hamamtsu S11639 detector.
- Wavelength ranges over 800nm, to be selected between 200nm and 1100nm, and a resolution of less than 1.9nm at 550nm.
- O-Spectrometer is sold calibrated (+/- 0.5nm) and has USB 2.0.
- The Halogen light source is cooled with an internal fan and can be equipped US or EU plug.
- Deuterium -Halogen Light Source
- It provides a broad, continuous spectrum between 190nm and 2500nm (Deuterium – Halogen) or 350-2000nm (Halogen).
Top Applications
- Gemology
- Biology
- Analyze emitted light from any light source (Vis-NIR).
- Absorbance and Transmittance.
- Fluorescence.
- Measure Absorbance and Densities.
