R-Spectrometer

$390

  • EUR: €335

The calibrated refurbished laboratory quality USB Spectrometer with a wavelength interval of 250nm ranging between 400nm and 650nm (+/- 30nm).

The low-cost spectrometer is a premium-quality device. It offers a wide range of functions and is far more cost-effective than its high-end counterparts. It is a worthwhile investment for basic experiments and small-scale processes.

The R-Spectrometer is a reconditioned compact fiber-coupled CCD spectrometer. It is crossed the Czerny-Turner design and built on Sony ILX511 linear CCD along with a 100 µm slit width.

The 1800l/mm diffraction grating is inside and powered with 5V DC.  The wavelength interval of 250nm range between 400nm and 650nm (+/- 30nm).

The offer includes a research-grade license (for non-commercial use) of Spectragryph – optical spectroscopy software.



Weight 850 g
Dimensions 15 × 10.6 × 4.8 cm
Optical Bench - Symmetrical Czerny-Turner focal length (mm)

75

Wavelength range (nm)

400-650nm(+/-30nm)

Resolution (nm)

<1

Slit Width (µm)

100

Sensitivity counts/μW per ms integration time

310.000

Stray-light

>5%

Detector

Sony ILX511 CCD linear array

Chip Dim (pixels)

2048×1152

Signal/noise

Better than 200:1

AD converter

16-bit

Integration time

50ms-1.1mn

Interface

RS232 to USB

Data transfer speed

350 ms/scan

Power Supply

5VDC

Temperature range (°C)

0-55

Software

Spectragryph – optical spectroscopy software.

Order processing time

6 days
